I/P: 3∮,O/P: 1∮Series (Hi-Frequency)

I/P: 3∮,O/P: 1∮Series (Hi-Frequency)

I/P: 3∮,O/P: 1∮Series (Hi-Frequency)
*10KVA-20KVE-2
*2704

列印..

轉寄..

*

Features:

 True Sinewave Double Conversion On-Line UPS

Microprocessor Control Guarantees High Reliability

Extended Back-up Time with External Battery Bank

Unite Input Power Factor and Wide Input Range

DC Start and Automatic Self-diagnostic Function

RS-232 Communication Port and Built-in SNMP Slot

High Efficiency Design to save Electricity

Low Heat Dissipation in Long Time Operation

Designed to operate under Harsh Environment

Enhanced Protections against Lightning Surges, Disturbances and etc

3Phase for Input & 1Phase for Output

Specification:

Model



3P1-HF15K

3P1-HF20K

Capacity



15KVA/10.5KW

20KVA/14KW

Input

Phase

3P4W+G

Frequency Range

50Hz or 60Hz (Auto Sensing)

Power Factor

0.95

Acceptable Voltage

304VAC~478VAC +/-3%

Output

Phase

1P2W+G or 1P3W+G(with ISO Transformer)

Voltage

220/230/240VAC or 110/220VAC;115/230VAC;120/240VAC

Voltage Regulation

+/- 1%(+/-2% with ISO Transformer)

Frequency

50Hz or 60Hz

Frequency(Battery Mode)

50Hz or 60Hz +/- 0.05 Hz

Overload Capacity

105% ~ 130% for 1 min,>130% for 1s

Crest Ratio

3:1

THD

2%(Linear Load) or 6%(Non-Linear Load)

Output Waveform

Pure Sinewave

Efficiency

To AC Mode

88%

To Battery Mode

88%





Battery

Battery Type

Depending on the capacity of external batteries.

Numbers of Batteries

Depending on the capacity of external batteries.

Back-up (Full load)

Depending on the capacity of external batteries.

Recharge Time

Depending on the capacity of external batteries.

Charging Current (Max.)

4.2A

Voltage

240V

Transfer time

AC to DC orlnverter to Bypass

Zero

Display

LED

Normal(Green),Bypass(Yellow),Inverter(Green),Battery(Yellow)

Load%(5 LED),Battery%(5 LED),Fault (Red)

LCD

UPS status, I/P & O/P Voltage & Frequency, Load %, Battery %, Temp



Audible Alarm

Battery Mode

Sounding every 4 seconds

Low Battery

Sounding every second

Overload

Sounding twice every second

Fault

Beeping continuosly

Dimension

UPS Case (D*W*H)

570*260*717mm

Battery Bank(D*W*H)

695*260*717mm

Weight

Main UPS (Net)

55Kgs

Battery Bank

Depending on the battery quantity

Environment

Operating Temperature

0 ~40°C (32°F ~ 104°F)

Acoustic Noise

< 60dB at 1M

Interface

Smart RS-232

Windows 98/NT/2000XP/2003/ME/Vista, Linux, Sun Solaris, IBM Aix,

Compaq True64, SGI IRIX, FreeBSD, HP-UX, and MAC

SNMP Slot

Power management from SNMP manager and Web browser (SNMP Optional)

Design, Manufacure, Sservice



ISO 9001-2000

Warranty



1 year
